管道外壁自動噴砂機
◆實用范圍內 Applicable scope
管類軸類零件,如:鐵管、彈簧鋼、螺桿式、螺桿式、大形圓形、圓罐類、圓形型產品;選擇雙槍(可按規定多槍)及風暴式除塵系統器和光電科技感應職能,升高了制造有效率及極大的限制了維修保養率。 (此儀器需既定)
The kind of pipe workpieces, such as: steel pipe, round steel, bars, screw, large cylindrical, cylinder, round the plant; Adopt double gun (according to demand more gun) and new filter and light electricity function, improve the production efficiency and reduce the maintenance rate. (the model need to customize)
◆通常新型號規格指標 Main technical parameters
絲機尺寸 Model |
STR-1500管道外壁自動噴砂機 |
STR-1800輥傳動雙槍自動噴砂機 |
的工作艙長寬高 Working class size(mm) |
1000×900×900 |
1800×900×1000 |
機器尺寸大小 Complete machine size(mm) |
1200×900×2900 |
1900×900×2900 |
壓縮成氣體源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
電 Power |
220v 50Hz |
220v 50Hz |
直流變頻空調同步電機變頻調速器 Governor |
250W×2 |
250W×2 |
分離法器無刷電機 Separator motor |
380v 50Hz 4kw |
220v 50Hz 1.1kw |
剝離器功率 Air separator |
35m3/min |
35m3/min |
廣州POS機含量 Machine weight |
900kg |
900kg |
