本噴砂機適用于10-490mm長度的分類軸類的內在因素、外在環境外表通常看上去創意手工運營噴砂作業管理,祛除外外表通常看上去的污痕、外表通常看上去防銹、外表通常看上去武器鍛造、增強很糙度、取除外表通常看上去壓力等。(列舉:電飯煲、杯具、不粘鍋、蘋果六手機機殼、租賃機殼、水泵葉輪、圓鋸片孩他)可按老客戶要訂制單工作臺面或雙工作臺面。
The sandblasting machines apply to 10-490 mm diameter of of all kinds of the internal and external surfaces of the manual operation sandblast homework, remove the dirt, surface derusting appearance, surface strengthening and improving roughness, removing surface stress, etc. (for example: electric meal bao, cup with, titanium, cell phone casing, computer shell, impeller, saw blades, etc) make single or double position according to customers' special requirements.
◆主要的技術設備指標 Main technical parameters
機主要參數 Model |
STR-A1500型12槍圓筒轉回式 |
STR-A1600型八槍圓球傾動式 |
STR-A1600型十四槍圓板回升式 |
組裝機大小 Complete machine size(mm) |
1500×2160×3000 |
1600×1800×2500 |
2200×2400×3000 |
事情艙尺寸大小 Working class size(mm) |
Φ1400 |
Φ1500 |
Φ2000 |
除塵處理箱規格 Dedust box sizes(mm) |
1000×1200×2500 |
1000×1200×2500 |
1400×1400×2500 |
小轉盤數 The small turntable for |
16個 |
8個 |
8個 |
噴槍數 Gun number |
12把 |
8把 |
14把 |
電源模塊 Power |
380V三相四線電 |
380V三相電源電 |
380V三相電電 |
照明 Floodlight |
2盞防震燈 |
2盞防爆設備燈 |
2盞防燃燈 |
廣州POS機承重 Machine weight |
800kg |
750kg |
800kg |
