◆企業產品特殊性 Product features
1. 來設計有新意,外觀外觀,環保健康功能好;
2. 可調節為式漩風拆分器,能將能用爐料與很小粉塵濃度拆分,好的爐料堅持用;
3. 其主要零部件的按照高質進品零件圖,選用壽命短長;
4. 生產制造鏜孔外層飽滿;
5. 多鉗臺開發;工作員可此外工作噴砂。隨著的客戶標準,先選擇半手動或手動 ;可按加盟商必須生產廠家!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆使用標準 Applicable scope
木板材,電腦主機金屬外殼,音箱蓋板,面包烤盤等品面及方體工件產品的噴砂加工生產。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆具體技巧參數表 Main technical parameters
電腦規格 Model |
STR-多工位輸送式噴砂機 |
主機大小 Complete machine size(mm) |
3000×1000×1700 |
辦公空間 Work space(mm) |
2000×1000×800 |
外傳送長寬比 Conveying the size(mm) |
500×1000×1000(2件) |
收塵箱尺寸 Dedust box sizes(mm) |
600×600×1800 |
隔離器交流電動機 Separator motor |
220V 50HZ 550W |
分離處理器功率 Separator air volume |
8.5m3/min |
壓縮視頻室內空氣源 Compressed air source |
2-8bar(kg/cm2) |
噴槍 Spray gun |
2把 |
照明 Floodlight |
兩盞30W防燃燈 |
機械重量體積 Machine weight |
550kg |
