◆能力指標 Main technical parameters (請從上到下閱覽有個量案例分析圖片視頻供分類)
絲機規格型號 Model |
STR-9070/9080 |
STR-1010 |
做工作艙的尺寸 Internal size(mm) |
900×800×650 |
1000×1000×790 |
機器圖片尺寸 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
24v電源 Power |
220V 50Hz |
220V 50Hz |
系統光照燈 Machine floodlight |
一盞燈60W防爆型燈 |
220V 13W工業LED燈 |
滾筒承受力 Roller bearing |
10-30Kg |
10-30Kg |
分離出來器馬達 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
分開器排風量 Separator air volume |
8.5m3/min |
8.5m3/min |
收縮新鮮空氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
器機單重 Weight |
320kg |
380 kg |
◆物料優勢 Product features
1. 定制刺激、自然大方縣、構成學科、進行操作便宜;
2. 自行把控好自行噴砂,擁有指定時間噴砂,點動定位手機等的功能;
3. 滾簡外徑及噴槍數可依照消費者消費需求設計制成制成;
4. 就可以了手動擋,又可智能,噴砂產品好,一機要用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆可用依據 Applicable scope
采用做大批量小鋼件的速騰半自動檔或半自動噴砂,這類:電木質品、鏍絲、塑料制品制
品、鈕扣、拉鎖、亞克力、POS機零構件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
